Description
การออกแบบ THUNDERWEB มีลักษณะเป็นใยรูปทรงกรวยซึ่งจะหนาขึ้นที่ด้านหลังของดอกสว่าน ดอกสว่านมาตรฐานมีความหนาคงที่ตลอดความยาว แม้ในจุดที่แคบที่สุด แกน THUNDERWEB ก็หนากว่าดอกสว่านมาตรฐาน
MILWAUKEE ดอกเจาะเหล็ก HSS-G
MILWAUKEE ดอกเจาะเหล็ก HSS-G
แบรนด์
รุ่น
N/A
ดาวน์โหลดเอกสาร
| Model | Steel Size | Total length (mm) | Working length (mm) | Add to Cart |
|---|---|---|---|---|
| 4932352345 | 1.0x34 mm | 34 | 18 | |
| 4932352346 | 1.5x40 mm | 40 | 24 | |
| 4932352347 | 2.0x49 mm | 49 | 24 | |
| 4932352348 | 2.5x57 mm | 57 | 30 | |
| 4932352349 | 3.0x61 mm | 61 | 33 | |
| 4932352350 | 3.2x65 mm | 65 | 36 | |
| 4932352351 | 3.5x70 mm | 70 | 39 | |
| 4932352352 | 4.0x75 mm | 75 | 43 | |
| 4932352353 | 4.2x80 mm | 80 | 47 | |
| 4932352354 | 4.5x80 mm | 80 | 47 | |
| 4932352355 | 4.8x86 mm | 86 | 52 | |
| 4932352356 | 5.0x86 mm | 86 | 52 | |
| 4932352357 | 5.5x93 mm | 93 | 57 | |
| 4932352358 | 6.0x93 mm | 93 | 57 | |
| 4932352359 | 6.5x101 mm | 101 | 63 | |
| 4932352360 | 6.8x109 mm | 109 | 69 | |
| 4932352361 | 7.0x109 mm | 109 | 69 | |
| 4932352362 | 7.5x109 mm | 109 | 69 | |
| 4932352363 | 8.0x117 mm | 117 | 75 | |
| 4932352364 | 8.5x117 mm | 117 | 75 | |
| 4932352365 | 9.0x125 mm | 125 | 81 | |
| 4932352366 | 9.5x125 mm | 125 | 81 | |
| 4932352367 | 10.0x133 mm | 133 | 87 | |
| 4932352368 | 10.5x133 mm | 133 | 87 | |
| 4932352369 | 11.0x142 mm | 142 | 94 | |
| 4932352370 | 11.5x142 mm | 142 | 94 | |
| 4932352371 | 12.0x151 mm | 151 | 101 | |
| 4932352372 | 12.5x151 mm | 151 | 101 | |
| 4932352373 | 13.0x151 mm | 151 | 101 |
ลักษณะเด่น
- THUNDERWEB design is characterised by a conical shaped web which gets thicker towards the back of the drill bit. Standard drill bits have a constant thickness throughout their length. Even at the narrowest point the THUNDERWEB core is thicker than that of a standard drill bit.
- Parabolic web cross section: Large web thickness. Strength built in.
- Flute geometry – THUNDERWEB flute form ejects hot chips rapidly. Dissipates heat better increasing life time.
- 135° Split point – Precision starting, drill bit won’t walk on material surface.
- Polished finish reduces friction and extends drill bit life.
- Impact resistant ABS case with added rubber corner protection.
- Accepts higher feed pressure and torque equalling less breakages.
